| 項目 | 說明 |
|---|---|
| 材質: MATERIAL: |
聚氯乙烯+聚甲醛 PVC+NYLON(V0) |
| 厚度: THICKNESS: |
0.35MM |
| 顏色: COLOR: |
黑+銀灰 BLACK+SILVER GREY |
| 表面電阻: SURFACE RESISTANCE: |
4.0 × 10¹¹Ω |
| 功能: FUNCTIONS: |
保護並美化配線,拆卸方便,可重複使用 PROVIDES PROTECTION AND A CLEAN APPEARANCE FOR WIRING, EASY TO REMOVE AND FULLY REUSABLE. |
| 用途: USAGE: |
適用於分叉電纜的保護 DESIGNED FOR THE PROTECTION OF BRANCHED CABLE ASSEMBLIES. |
| 項目 | 橫向 / TRANSVERSE | 縱向 / LONGITUDINAL |
|---|---|---|
| 撕裂強度: TEAR STRENGTH: |
65.7N | 56.3N |
| 拉伸強度: TENSILE STRENGTH: |
727N | 921N |
| 伸長率: ELONGATION: |
22% | 20% |
| 型號 MODEL |
寬度(mm) WIDTH(mm) |
條徑(mm) DIAMETER(mm) |
長度 LENGTH |
包裝方式 PACKAGING |
|---|---|---|---|---|
| YB-BG-10 | 62 | Φ10 | 50M | 紙盒 PAPER BOX |
| YB-BG-15 | 75 | Φ15 | ||
| YB-BG-20 | 90 | Φ20 | ||
| YB-BG-25 | 105 | Φ25 | ||
| YB-BG-30 | 120 | Φ30 | ||
| YB-BG-40 | 150 | Φ40 | ||
| YB-BG-50 | 180 | Φ50 | ||
| YB-BG-70 | 242 | Φ70 | ||
| YB-BG-100 | 335 | Φ100 |
